Computer system requirements:
Below are the minimum computer-system requirements for the FireStudio Mobile:
Windows
- Windows® XP SP3, Vista x64/x32 SP2, Windows 7 x64/x32 SP, Windows 8 x64/x32
- Intel® Core™ Duo or AMD Athlon™ X2 processor (Intel Core 2 Duo or AMD Athlon X4 or better recommended
- 2 GB RAM (4 GB or more recommended)
Mac
- Mac® OS X 10.6.8 or later
- Intel Core Duo processor (Intel Core 2 Duo or Intel Core i3 or better recommended)
- 2 GB RAM (4 GB or more recommended)
Windows and Mac Systems
- FireWire (IEEE 1394) port
- Internet connection (only for activation)
- DVD-ROM drive
- Monitor with at least 1024x768 resolution
- 20 GB hard-disk space
- Internal or external 7200 RPM storage drive highly recommended
The minimum system requirements may differ for DAWs other than Studio One. Please check the requirements for your DAW of choice with its manufacturer.
Note that the speed of your processor, amount of RAM and size and speed of your hard drive will greatly affect the overall performance of your recording system. Also, a more powerful system (faster processor with more RAM) will allow for lower latency (signal delay) than you might experience while monitoring audio or MIDI signals. Monitor resolution for both PC and Macintosh should be no lower than 1024x768 pixels.
Known compatible and incompatible hardware
Microphone Preamp
|
| Type |
XLR Female Balanced |
| Frequency Response (+0, -0.5 dB) |
20 Hz to 50 kHz |
| Frequency Response (+0/, -3.0 dB |
20 Hz to 150 kHz |
| Input Impedance |
1.6 kΩ |
| THD + N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) |
< 0.008% |
| EIN (unwtd, 55 dB Gain, 150Ω Input, 20 Hz to 22 kHz) |
-130 dBu |
| S/N Ratio (Unity Gain, unwtd, Ref = +4 dBu, 20 Hz to 22 kHz) |
>101 dB |
| Common Mode Rejection Ratio (1 kHz, 55 dB Gain) |
>55 dB |
| Gain Control Range (± 1 dB) |
–10 dB to 70 dB |
| Maximum Input level (Unity Gain, 1 kHz@0.5% THD+N) |
+14 dBu |
| Phantom Power (± 2 VDC) |
+48 VDC |
Instrument Input (¼" TRS, Channels 1 & 2)
|
| Type |
TS Female Unbalanced |
| Input Impedance |
1 MΩ |
Line Inputs (Channels 3-8)
|
| Type |
TRS Female Balanced |
| Frequency Response (+0, -5 dB) |
20 Hz to 50 kHz |
| Frequency Response (+0/-3.0 dB) |
20 Hz to 150 kHz |
| Input Impedance |
10 kΩ |
| THD + N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) |
< 0.002% |
| S/N Ratio (Unity Gain, unwtd, Ref = +4 dBu, 20 Hz to 22 kHz) |
>101 dB |
| Maximum Input level (1 kHz @ 0.5% THD+N) |
+10 dBu |
Main Outputs
|
| Type |
¼” TRS Impedance Balanced |
| Output Impedance |
51Ω |
Headphone Output
|
| Type |
¼” TRS Active Stereo |
| Maximum Output |
150 mW/Ch. @ 60Ω Load |
| Frequency Response |
10 Hz - 70 kHz |
Digital Audio
|
| FireWire (IEEE 1394) Speed |
400 Mbps |
| ADC Dynamic Range (A-wtd, 48 kHz) |
118 dB |
| DAC Dynamic Range (A-wtd, 48 kHz) |
118 dB |
| Bit Depth |
24 bits |
| Reference Level for 0 dBFS |
+10 dBu |
| Internal Sample Frequency Selections |
44.1, 48, 88.2, 96 kHz |
| Clock Jitter |
<20 ps RMS (20 Hz – 20 kHz) |
| Clock Jitter Attenuation |
>60 dB (1 ns in => 1 ps out) |
Power
|
| Bus Power |
6-pin FireWire 400 or FireWire 800 |
| Power Supply |
External Switching Supply (12 VDC/1A) |
Physical
|
| Dimensions |
1/3U rack-mount (with standard rack tray, not included) |
| Height |
1.75” (44.45 mm) |
| Depth |
5.5” (139.7 mm) |
| Width |
5.5” (139.7 mm) |
| Weight |
4.5 lbs (2 kg) |
As a commitment to constant improvement, PreSonus Audio Electronics, Inc., reserves the right to change any specification stated herein at anytime, without notification.
|
|
