This product has been discontinued.
Computer system requirements:
Below are the minimum computer-system requirements for your FP10.
Windows
- Windows XP SP3 or later (32-bit), Vista (32/64-bit), Windows 7 (32/64-bit)
- Intel Pentium 4 1.6 GHz processor or AMD Athlon 64 (Turion) (2.5 GHz or faster recommended)
- 1 GB RAM (2 GB or more recommended)
Mac
- Mac OS X 10.3.7 or later (10.4.11, 10.5.2 or later, or 10.6 recommended)
- PowerPC G4 1.25 GHz or Intel Core Solo 1.5 GHz processor (2 GHz or faster recommended)
- 1 GB RAM (2 GB or more recommended)
Windows and Mac Systems
- IEEE 1394 FireWire 400 Port
- Internet connection recommended
- DVD-ROM drive
- Internal or external 7200 RPM storage drive highly recommended
Note that the speed of your processor, amount of RAM and size and speed of your hard drive will greatly affect the overall performance of your recording system. Also, a more powerful system (faster processor with more RAM) will allow for lower latency (signal delay) that you might experience while monitoring audio or MIDI signals.
Monitor resolution for both PC and Macintosh should be no lower than 1024x768 pixels.
Technical Specifications
Microphone Preamp 1-8 (XLR Balanced) |
|
| Type |
XLR Female Balanced |
| Frequency Response (±0.5 dB) |
20 Hz to 50 kHz |
| Frequency Response (±3.0 dB) |
20 Hz to 150 kHz |
| Input Impedance (Balanced) |
1600 Ohm |
| THD+N (unwtd, 1kHz @ +4 dBu Output, Unity Gain |
< 0.005% |
| EIN (unwtd, 55dB Gain, 150 Ω Input, 20Hz to 22kHz |
-125 dBu |
| S/N Ratio (Unity Gain, unwtd, Ref. = +4 dBu, 20Hz to 22 kHz |
> 101dB |
| Common Mode Rejection Ratio (1 kHz, 55 dB Gain) |
> 55dB |
| Gain Control Range (± 1dB) |
-4 dB to 50dB |
| Maximum Input Level (Unity Gain, 1 kHz @ 0.5% THD+N) |
+14 dBu |
| Phantom Power (±2 VDC) |
+48 VDC |
Instrument Input (1/4" TS input channels 1-2) |
|
| Type |
1/4" TS |
| Input Impedance |
1 Mega Ohm |
Line Inputs (1/4” TRS input channels 3-8) |
|
| Frequency Response (+0,- 0.5dB) |
20Hz to 50kHz |
| Frequency Response (+0/-3.0 dB) |
20Hz to 150kHz |
| Input Impedance (Balanced) |
10 KOhm |
| THD+N (unwtd, 1KHz @ +4dBu Output, Unity Gain) |
< 0.003% |
| S/N Ratio (Unity Gain, unwtd, Ref. = +4dBu, 20Hz to 22KHz) |
>101dB |
| Maximum Input Level (Unity Gain, 1KHz @ 0.5% THD+N) |
+20dBu |
Line Outputs (1/4" TRS) |
|
| Output Impedance |
51 Ohms |
| Cue and Main Output Impedance |
51 Ohms |
Headphone Output |
|
| Type |
TRS Active Stereo |
| Maximum Output |
150 mW/CH @ 60 Ohm Load |
| Frequency Response (±1.0 dB) |
20 Hz - 20kHz |
Digital Audio |
|
| FireWire (IEEE 1394) Speed |
400mbps |
| ADC Dynamic Range (Awtd, 48 kHz Sample Rate) |
107 dB |
| DAC Dynamic Range (Awtd, 48 kHz Sample Rate) |
107 dB |
| Bit Depth |
24 |
| Internal Sample Frequency Selections (kHz) |
44.1, 48, 88.2, 96 |
| Simultaneous record/playback channels and sample rate |
Single Unit (10 in, 10out @ 24/96K)
Two FP10's (up to 16 in/out @ 24-bit/ 44.1k or 48K)
Three FP10's (up to 24 in/out @ 24-bit/44.1k or 48k)
Note: FP10's and FirePod's can be daisy-chained |
Power |
|
| Input Connector Type |
IEC |
| Input Voltage (factory configured) |
90 to 240 VAC |
| Power Requirements (Continuous) |
20W |
| Internal Sample Frequency Selections (kHz) |
44.1, 48, 88.2, 96 |
Physical |
|
| Main Chassis |
| Package type |
1U - steel chassis |
| Dimensions |
19"x1.75"x7" |
| Weight |
8 lbs |
As a commitment to constant improvement, PreSonus Audio Electronics, Inc., reserves the right to change any specification stated herein, at any time, without notification.
